11kw 15HP oil-free food packaging air compressor

As one of the packing compressor manufacturers, suppliers, and exporters of mechanical products, We offer packing compressor and many other products.

Please get in touch with us for details.

Mail:[email protected]

Packing Compressor

ep-packing-compressor-1bacj-1

Packing compressors are a form of compressor that makes use of packing to make sure that the piston and cylinder are sealed. It is composed of a set of rings that are compressed between the piston and the cylinder's wall. This seals the cylinder and stops gas from flowing through the piston.

The packing compressor is typically employed in situations that require high pressure. They can also be used in situations where the compressed gas is toxic or corrosive. The compressors for packing can be found in a variety of capacities and sizes. They are available as one-stage or multi-stage.

Single-stage compressors for packing are the most straightforward type of packing machine. They comprise three components: a cylinder, a piston, and packing. It is powered by the crankshaft. It can compress the gas when it is moved through the cylinder. The packing seals the piston as well as the cylinder, preventing gas from leakage through the piston.

Packing Compressor Technical Parameters

Model
Parameter
10 15 20 25 30 40 50 60 75 100
Air flow m3/min
Pressure Mpa
1.2/0.7 1.65/0.7 2.5/0.7 3.2/0.7 3.8/0.7 5.3/0.7 6.8/0.7 7.4/0.7 10/0.7 13.4/0.7
1.1/0.8 1.5/0.8 2.3/0.8 3.0/0.8 3.6/0.8 5.0/0.8 6.2/0.8 7.0/0.8 9.6/0.8 12.6/0.8
0.95/1.0 1.3/1.0 2.1/1.0 2.7/1.0 3.2/1.0 4.5/1.0 5.6/1.0 6.2/1.0 8.5/1.0 11.2/1.0
0.8/1.2 1.1/1.2 1.9/1.2 2.4/1.2 2.7/1.2 4.0/1.2 5.0/1.2 5.6/1.2 7.6/1.2 10.0/1.2
Lubricant L 10 18 30 65
Noise 66±2 68±2 72±2
Driving way Direct Driven
Power Supply 380V/50Hz
Power HP 10 15 20 25 30 40 50 60 75 100
Starting way Y DELTA
Dimension L mm 900 1080 1380 1500 1700
W mm 670 750 850 1000 1200
H mm 845 1015 1175 1335 1630
Weight KG 220 380 500 700 1200
Outlet pipe diameter G1/2 G3/4 G1 G1-1/2 G2
Model
Parameter
125 150 175 200 250 300 350 430 480 540
Air flow m3/min
Pressure Mpa
16.2/0.7 21.0/0.7 24.5/0.7 28.7/0.7 32/0.7 36/0.7 42/0.7 51/0.7 64.0/0.7 71.2/0.7
15.0/0.8 19.8/0.8 23.2/0.8 27.6/0.8 30.4/0.8 34.3/0.8 40.5/0.8 50.2/0.8 61.0/0.8 68.1/0.8
13.8/1.0 17.4/1.0 20.5/1.0 24.6/1.0 27.4/1.0 30.2/1.0 38.2/1.0 44.5/1.0 56.5/1.0 62.8/1.0
12.3/1.2 14.8/1.2 17.4/1.2 21.5/1.2 24.8/1.2 27.7/1.2 34.5/1.2 39.5/1.2 49/1.2 52.2/1.2
Lubricant L 72 90 110 125 150 180
Noise 72±2 75±2 82±2 84±2
Driving way Direct Driven
Power Supply 380V/50Hz
Power HP 125 150 175 200 250 300 350 430 480 540
Starting way Y DELTA
Dimension L mm 1700 2300 2500 3150
W mm 1200 1470 1470 1980
H mm 1630 1840 1840 2150
Weight KG 1200 2000 2200 3500 4000 4500 6000 6500 7200
Outlet pipe diameter G2 G2-1/2 DN85 DN100

Packing Compressor Features

Simple design Compressors for packing are relatively easy to create and build.

The construction of packing compressors is robust. They typically are constructed of durable material

Flexible Packing compressors can be utilized in a range of different applications, such as vacuum pumping, air compression as well as refrigeration.

Effective Compressors that pack are extremely efficient, particularly when compared with other kinds of compressors, like reciprocating compressors.

We are one of the best packing compressor suppliers. Due to our excellent product quality and after-sales service, we have exported our products to clients all over the world and won a good reputation. Welcome customers at home and abroad to contact us, negotiate business, exchange information, and cooperate with us!
